FunctionBay RecurDyn V9R5 – FunctionBay Company is one of the pioneers in the manufacture of Computer Aided Engineering Software, one of the company’s most powerful software.

The software uses a very powerful computational system based on recursive expressions, combining multibody dynamics and nonlinear finite element methods. In addition, other computational engineering technologies such as system control modeling and system-level nonlinear optimization, where the software is applied to many industries such as automotive, shipbuilding, railroad, robotics, heavy industry, military, mechanical equipment, and electronics.

Also supports. Features include CoLink design, fatigue analysis, application peripherals, application customization, product innovation, user-optimized design tools to save time and reduce costs associated with designing and simulating manufactured products. It is included. Slowly

With this software, users design models using all the basic elements such as body, lever and force, joints and contacts, and Cada files in Parasolid, STEP, IGES, ACIS, CATIA format. It can be imported and edited. Slow to create equipment models, define equipment elements, display in animationOr mark the plan.

The user can also create different conditions for testing and finding product defects and then eliminate these defects. Using the tools embedded in the software, each user can customize the software according to their needs. The MFBD analysis capability, which combines the MBD method with the finite element method, is flexible to simulate moving sets, and the user can accurately analyze dynamic stresses and analyze system levels based on criteria such as surface painting. Specify different and inertial forces variable with time.

Here are some key features of “FunctionBay RecurDyn V9R5 BN9509”:

  • Supports integrated multi-discipline dynamics based on MFBD (Multi Flexible Body Dynamics)
  • The solution includes a control (CoLink design)
  • Fatigue analysis
  • Application toolkits
  • Function of user customization (ProcessNet)
  • Tool of design optimization (AutoDesign)

System Requirement

  • HARDWARE REQUIREMENTS
    – 64-bit
  • Minimum Recommended
    CPU 2.4GHz 3.4GHz, Quad Core ”
    Memory (RAM) 8GB 32GB
    Free Dis k Space lOGB lTB
    Display Adapter OpenGL OpenGL 4 .0
    Screen Resolution 1024 * 768 1920 * 1080
    ODD DVD-R (DL ) or above



  • Operating System : Microsoft Windows 64-bit
    Windows 10
    Windows Server 2012 R2
    Windows Server 201 2
    Windows Server 2016
    Windows Server 2019

    • RecurDyn only supports 100% size of apps and text on the display.

    • Recommended OpenGL version
    – RecurDyn minimum OpenGL version required: 4 .0
    – Graphic problems can occur if a machine’s OpenGL version is lower than 4.0.
    – OpenGL version will be detected as 1 .1 .0 when using the remote desktop connection.
